SPU1-5 Series
Manufacturer: Polytron
Beta
⌘K
DC DC CONVERTER +/-15V 990MW
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Efficiency | Voltage - Input (Max) [Max] | Type | Power (Watts) | Package / Case | Applications | Mounting Type | Number of Outputs | Voltage - Output 2 | Voltage - Input (Min) [Min] | Current - Output (Max) [Max] | Current - Output (Max) [Min] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Output 1 | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Polytron | 85 °C | -25 °C | 78 % | 5.5 V | Isolated Module | 0.99 W | 7-SIP Module 5 Leads | ITE (Commercial) | Through Hole | 2 | -15 V | 4.5 V | 33 mA | 33 mA | 0.4 " | 10.2 mm | 6.1 mm | 19.6 mm | 0.24 " | 0.77 in | 15 V | 1000 V |
