857-074 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 74POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Card Type | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Color | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Termination | Read Out | Contact Type | Gender | Contact Finish | Features | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 74 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Gold | Card Extender | Copper Alloy |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Through Hole | 74 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Wire Wrap | Dual | Semi Bellows | Female | Gold | Copper Alloy | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 74 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Gold | Card Extender | Copper Alloy |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Through Hole | 74 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Tin | Copper Alloy | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Through Hole | 74 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Wire Wrap | Dual | Semi Bellows | Female | Tin | Copper Alloy | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Through Hole | 74 | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Tin | Copper Alloy | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Board Edge Straddle Mount | 74 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Tin | Card Extender | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Through Hole | 74 | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder Eyelet(s) | Dual | Semi Bellows | Female | Gold | Copper Alloy | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Board Edge Straddle Mount | 74 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder | Dual | Semi Bellows | Female | Tin | Card Extender | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Through Hole | 74 | 125 °C | -40 C | 3.96 mm | 0.156 in | Black | 37 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Solder Eyelet(s) | Dual | Semi Bellows | Female | Gold | Copper Alloy |
