630W3W Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB MIXED CONTACT CONNECTORS RIGHT-ANGLE WATERPROOF POWER COMBO D-SUB CONNECTOR
| Part | Dielectric Material | Voltage Rating | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Termination | Contact Finish | Shell Material, Finish | Flange Feature | Number of Rows | Features | Mounting Type | Connector Style | Ingress Protection | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout | Current Rating (Amps) | Contact Type | Number of Positions | Shell Size, Connector Layout | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell (M3) | 1 | Board Lock Mounting Brackets Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | 0.38 µm | 15 µin | 2 (DA A) - 3W3 | 10 A | Power | 3 | |||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell (M3) | 1 | Board Lock Mounting Brackets Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Plug Female Sockets and Male Pins | 0.76 Ám | 30 Áin | 3WK3 A DA | 30 A | Power | 3 | 2 | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell | 1 | Mounting Brackets Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 2 (DA A) - 3W3 | 30 A | Power | 3 | 4-40 | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell | 1 | Board Lock Mounting Brackets Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Plug Female Sockets and Male Pins | 0.127 µm | 5 µin | 3WK3 A DA | 10 A | Power | 3 | 2 | 4-40 | |
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell | 1 | Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 2 (DA A) - 3W3 | 30 A | Power | 3 | 4-40 | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell (M3) | 1 | Mounting Brackets Shielded | Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Plug Female Sockets and Male Pins | 0.38 µm | 15 µin | 3WK3 A DA | 20 A | Power | 3 | 2 | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell (M3) | 1 | Mounting Brackets Shielded | Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Plug Female Sockets and Male Pins | 3WK3 A DA | 20 A | Power | 3 | 2 | Flash | |||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell | 1 | Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | 0.38 µm | 15 µin | 2 (DA A) - 3W3 | 40 A | Power | 3 | 4-40 | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell | 1 | Board Lock Mounting Brackets Shielded | Panel Mount Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Plug Female Sockets and Male Pins | 0.38 µm | 15 µin | 3WK3 A DA | 20 A | Power | 3 | 2 | 4-40 | |
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | UL94 V-0 | Solder | Gold | Nickel Plated Steel | Housing/Shell (M3) | 1 | Mounting Brackets Shielded | Right Angle Through Hole | Combo D-Sub | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | 0.38 µm | 15 µin | 2 (DA A) - 3W3 | 20 A | Power | 3 |
