DL60H Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HERM RECP
| Part | Applications | Shell Size - Insert | Shielding | Qualification | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Mating | Shell Finish | Color | Connector Type | Primary Material | Number of Positions | Fastening Type | Mounting Feature | Contact Material | Shell Material | Mounting Type | Orientation | Insert Material | Cable Opening | Cable Opening | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | Aerospace | 10-5 | Unshielded | MIL-DTL-83723 Series III | -65 ░C | 200 °C | Gold | Tin | Silver | Receptacle Male Pins | Metal | 5 | Bayonet Lock | Flange | Nickel Iron Alloy | Steel | Panel Mount | 6 | Glass | |||
TE Connectivity AMP Connectors | Aerospace | 10-5 | Unshielded | MIL-DTL-83723 Series III | -65 ░C | 200 °C | Gold | Tin | Silver | Receptacle Male Pins | Metal | 5 | Bayonet Lock | Flange | Nickel Iron Alloy | Steel | Panel Mount | 9 | Glass | |||
 TE Connectivity AMP Connectors | Aviation Marine Military | 10-6 | Unshielded | MIL-DTL-83723 Series III | -55 C | 200 °C | Gold | Tin | Silver | Receptacle Male Pins | Metal | 6 | Bayonet Lock | Flange | Nickel Iron Alloy | Steel | Panel Mount | Elastomer Glass | 0.562 in | 14.27 mm | N (Normal) |
