846-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 21POS 0.125
| Part | Termination Rows | Material - Insulation | Color | Number of Positions/Bay/Row [custom] | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Type | Termination | Read Out | Gender | Card Type | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Wire Wrap | Single | Female | Non Specified - Single Edge | Copper Alloy | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Solder | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Wire Wrap | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Wire Wrap | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Solder | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Solder | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Wire Wrap | Single | Female | Non Specified - Single Edge | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Solder | Single | Female | Non Specified - Single Edge | Copper Alloy | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Solder | Single | Female | Non Specified - Single Edge | Copper Alloy | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 21 | 1 | 0.25 Ám | 10 Áin | Gold | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 21 | Cantilever | Wire Wrap | Single | Female | Non Specified - Single Edge | Copper Alloy | 4-40 Threaded Insert Top Mount Opening |
