ECO-S1 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
CAP ALUM 5600UF 20% 35V SNAP TH
| Part | Mounting Type | Lead Spacing | Lead Spacing | Polarization | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Size / Dimension [diameter] | Size / Dimension [diameter] | Package / Case | ESR (Equivalent Series Resistance) | Operating Temperature [Min] | Operating Temperature [Max] | Capacitance | Ripple Current @ Low Frequency | Tolerance | Voltage - Rated | Applications | Ripple Current @ High Frequency | Lifetime @ Temp. | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 37 mm | 1.457 in | 22 mm | 0.866 in | Radial Can - Snap-In | 74 mOhm | -40 °C | 105 ░C | 5.6 mF | 2.4 A | 20 % | 35 V | General Purpose | 2.76 A | 3000 Hrs | ||
Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 52 mm | 2.047 in | 22 mm | 0.866 in | Radial Can - Snap-In | 51 mOhm | -40 °C | 105 ░C | 2.9 A | 20 % | 35 V | General Purpose | 3.335 A | 3000 Hrs | |||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 52 mm | 2.047 in | 35 mm | 1.378 in | Radial Can - Snap-In | -40 °C | 105 ░C | 6800 µF | 3.9 A | 20 % | 80 V | General Purpose | 4.485 A | 3000 Hrs | |||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 40 mm | 1.575 in | 35 mm | 1.378 in | Radial Can - Snap-In | 26 mOhm | -40 °C | 85 °C | 22000 µF | 6.1 A | 20 % | 35 V | General Purpose | 7.015 A | 3000 Hrs | ||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 25 mm | 0.984 " | 22 mm | 0.866 in | Radial Can - Snap-In | 166 mOhm | -40 °C | 85 °C | 2200 µF | 1.52 A | 20 % | 35 V | General Purpose | 1.748 A | 3000 Hrs | ||
Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 22 mm | 0.866 in | Radial Can - Snap-In | 104 mOhm | -40 °C | 105 ░C | 2700 µF | 2.2 A | 20 % | 63 V | General Purpose | 2.53 A | 3000 Hrs | 42 mm | 1.654 in | ||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 27 mm | 1.063 in | 30 mm | 1.181 inches | Radial Can - Snap-In | 104 mOhm | -40 °C | 105 ░C | 2700 µF | 2.2 A | 20 % | 63 V | General Purpose | 2.53 A | 3000 Hrs | ||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 47 mm | 1.85 in | 25 mm | 0.984 " | Radial Can - Snap-In | 77 mOhm | -40 °C | 105 ░C | 3900 µF | 2.7 A | 20 % | 63 V | General Purpose | 3.105 A | 3000 Hrs | ||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 27 mm | 1.063 in | 25 mm | 0.984 " | Radial Can - Snap-In | 73 mOhm | -40 °C | 105 ░C | 6800 µF | 2.4 A | 20 % | 25 VDC | General Purpose | 2.76 A | 3000 Hrs | ||
 Panasonic Industrial Automation Sales | Through Hole | 0.394 in | 10 mm | Polar | 37 mm | 1.457 in | 20 mm | 0.787 in | Radial Can - Snap-In | 89 mOhm | -40 °C | 105 ░C | 5.6 mF | 2.2 A | 20 % | 25 VDC | General Purpose | 2.53 A | 3000 Hrs |
