120943 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONNECTOR, 5 CONTACTS, 1.5 MM, RECEPTACLE, PRESS FIT, 1 ROWS
| Part | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Positions | Connector Usage | Color | Termination | Number of Positions Loaded | Contact Finish | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Connector Style | Contact Layout, Typical |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | UL94 V-0 | -40 C | 105 ░C | Board Edge Right Angle Through Hole | 5 | Backplane | Gray | Press-Fit | All | Gold | Receptacle Female Blade Sockets | 50 µin | 1.27 µm | 1 | Blade Power | 5 Power |
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Board Edge Right Angle Through Hole | 8 | Backplane | Gray | Press-Fit | All | Gold | Receptacle Female Blade Sockets | 50 µin | 1.27 µm | 1 | Blade Power | 8 Power |
