ISL9120 Series

Manufacturer: Renesas Electronics Corporation

Catalog

COMPACT HIGH EFFICIENCY LOW POWER BUCK-BOOST REGULATOR

Part	Voltage - Output (Max) [Max]	Function	Voltage - Input (Max) [Max]	Number of Outputs	Voltage - Output (Min/Fixed)	Output Configuration	Output Type	Package / Case	Mounting Type	Voltage - Input (Min) [Min]	Topology	Current - Output	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output [Max]	Voltage - Output [Min]	Main Purpose	Board Type	Voltage - Input [Min]	Voltage - Input [Max]	Regulator Topology	Utilized IC / Part	Supplied Contents	Outputs and Type	Outputs and Type	Voltage - Output	Output Type
Renesas Electronics Corporation ISL9120IIAZ-T7A	5.2 V	Step-Up/Step-Down	5.5 V	1	1 V	Positive	Adjustable	9-UFBGA WLCSP	Surface Mount	1.8 V	Buck-Boost	800 mA	9-WLCSP (1.41x1.41)
Renesas Electronics Corporation ISL9120IIAZ-TR5696
Renesas Electronics Corporation ISL9120IRTAZ-T7A	5.2 V	Step-Up/Step-Down	5.5 V	1	1 V	Positive	Adjustable	12-WFQFN Exposed Pad	Surface Mount	1.8 V	Buck-Boost	800 mA	12-TQFN (3x3)	85 °C	-40 °C
Renesas Electronics Corporation ISL9120IIA-EVZ												800 mA				5 V	2 V	DC/DC Step Up or Down	Fully Populated	1.8 V	5.5 V	Buck-Boost	ISL9120	Board(s)	Non-Isolated	1
Renesas Electronics Corporation ISL9120IIN-EVZ												800 mA						DC/DC Step Up or Down	Fully Populated	1.8 V	5.5 V	Buck-Boost	ISL9120	Board(s)	Non-Isolated	1	3.3 V
Renesas Electronics Corporation ISL9120IIAZ-TR5654	5.2 V	Step-Up/Step-Down	5.5 V	1	1 V	Positive	Adjustable	9-UFBGA WLCSP	Surface Mount	1.8 V	Buck-Boost	800 mA	9-WLCSP (1.41x1.41)
Renesas Electronics Corporation ISL9120IINZ-TR5654		Step-Up/Step-Down	5.5 V	1	3.3 V	Positive		9-UFBGA WLCSP	Surface Mount	1.8 V	Buck-Boost	800 mA	9-WLCSP (1.41x1.41)															1.81 mOhm
Renesas Electronics Corporation ISL9120IRTAZ	5.2 V	Step-Up/Step-Down	5.5 V	1	1 V	Positive	Adjustable	12-WFQFN Exposed Pad	Surface Mount	1.8 V	Buck-Boost	800 mA	12-TQFN (3x3)	85 °C	-40 °C
