D40ML Series

Catalog

INTERLOCK RFID DPST

Part	Approval Agency	Voltage Rating	Termination Style	Operating Temperature [Min]	Operating Temperature [Max]	Features	Must Operate	Voltage - Supply	Must Release	Holding Force	Circuit	Actuator Type	Current Rating (Amps)	Type	Ingress Protection
Omron Electronics Inc-EMC Div D40ML-M2-U-5M	CE cULus	24 VDC	Cable Leads	-25 °C	40 °C	Magnetic Latching Status Indicator	1 mm	24 VDC	10 mm	91 kgf	DPST-NC	Non-Contact	200 mA	RFID	IP67 - Dust Tight Waterproof
Omron Electronics Inc-EMC Div D40ML-P2-U-10M
Omron Electronics Inc-EMC Div D40ML-P2-B-10M
Omron Electronics Inc-EMC Div D40ML-P1-B-M12
Omron Electronics Inc-EMC Div D40ML-P1-U-M12	CE cULus	24 VDC	Cable with Connector (M12)	-25 °C	40 °C	Magnetic Latching Status Indicator	1 mm	24 VDC	10 mm	153 kgf	DPST-NC	Non-Contact	200 mA	RFID	IP67 - Dust Tight Waterproof
Omron Electronics Inc-EMC Div D40ML-P2-B-ACT
Omron Electronics Inc-EMC Div D40ML-SS1-U-10M
Omron Electronics Inc-EMC Div D40ML-P2-B-M12	CE cULus	24 VDC	Cable with Connector (M12)	-25 °C	40 °C	Magnetic Latching Status Indicator	1 mm	24 VDC	10 mm	91 kgf	DPST-NC	Non-Contact	200 mA	RFID	IP67 - Dust Tight Waterproof
Omron Electronics Inc-EMC Div D40ML-SS2-U-5M	CE cULus	24 VDC	Cable Leads	-25 °C	40 °C	Magnetic Latching Status Indicator	1 mm	24 VDC	10 mm	61 kgf	DPST-NC	Non-Contact	200 mA	RFID	IP69K - Dust Tight High Temp Water Jets Waterproof
Omron Electronics Inc-EMC Div D40ML-SS1-B-M12
