857-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Type | Pitch | Pitch | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Contact Type | Color | Number of Positions/Bay/Row | Gender | Read Out | Number of Positions | Mounting Type | Contact Material | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | Semi Bellows | Black | 14 | Female | Single | 14 | Right Angle Through Hole | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 125 °C | -40 C | Solder | Semi Bellows | Black | 14 | Female | Single | 14 | Through Hole | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 125 °C | -40 C | Solder | Semi Bellows | Black | 7 | Female | Dual | 14 | Board Edge Straddle Mount | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 125 °C | -40 C | Wire Wrap | Semi Bellows | Black | 7 | Female | Dual | 14 | Through Hole | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 |
