3UG4621 Series
Manufacturer: Siemens
Beta
⌘K
DIGITAL MONITORING RELAY
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Circuit | Trip Range [Max] | Trip Range [Min] | Type | Contact Rating @ Voltage | Delay Time [Min] | Delay Time [Max] | Voltage - Supply [Max] | Voltage - Supply [Min] | Output Type | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Siemens | -25 °C | 60 °C | SPDT (1 Form C) | 600 mA | 3 mA | Current Sensing AC/DC | 3 A 400 VAC | 0.1 Sec | 20 s | 264 VAC | 20.4 VAC | Relay | DIN Rail |
 Siemens | -25 °C | 60 °C | SPDT (1 Form C) | 600 mA | 3 mA | Current Sensing AC/DC | 3 A 400 VAC | 0.1 Sec | 20 s | 264 VAC | 20.4 VAC | Relay | DIN Rail |
Siemens | -25 °C | 60 °C | SPDT (1 Form C) | 600 mA | 3 mA | Current Sensing AC/DC | 3 A 400 VAC | 0.1 Sec | 20 s | 26.4 VAC/DC | 20.4 VAC | Relay | DIN Rail |
 Siemens | -25 °C | 60 °C | SPDT (1 Form C) | 600 mA | 3 mA | Current Sensing AC/DC | 3 A 400 VAC | 0.1 Sec | 20 s | 26.4 VAC/DC | 20.4 VAC | Relay | DIN Rail |
