LB16RKW01 Series

Catalog

PUSHBUTTON SWITCH, LB SERIES, SPDT, ON-ON, RECTANGULAR, TRANSPARENT

Part	Electrical Life	Operating Temperature [Max]	Operating Temperature [Min]	Mechanical Life	Actuator Marking	Color - Actuator/Cap	Illumination Type, Color	Voltage Rating - AC	Switch Function	Termination Style	Actuator Type	Type	Voltage Rating - DC	Illumination Voltage (Nominal)	Current Rating (Amps)	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Circuit	Mounting Type
NKK Switches LB16RKW01-5F-JF	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Green LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	2.1 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5D24-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Amber LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	24 V	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-6B-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	LED White	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	3.3 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-01-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Neon White	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	110 VAC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5D-JD	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Amber LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	2 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5F05-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Green LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	5 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5C05-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	LED Red	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	5 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-6F-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Green LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	3.3 VDC	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5C24-JC	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	LED Red	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	24 V	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
NKK Switches LB16RKW01-5F24-JB	100000 Cycles	50 °C	-25 °C	200000 Cycles	No Marking	Clear	Green LED	125 V	On-On	Solder Quick Connect - 0.110" (2.8mm)	Button Rectangular	Illuminated Standard	30 V	24 V	3 A	16.2 mm	22.4 mm	SPDT	Panel Mount Snap-In
