82A0811 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

HOOK-UP DL WALL STRND 1/0AWG WHT

Part	Wire Gauge	Qualification	Operating Temperature	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Conductor Material	Jacket Color	Cable Type	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Thickness	Conductor Strand	Conductor Strand	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Diameter	Jacket (Insulation) Diameter
TE Connectivity AMP Connectors 82A0811-0-9-F874	44 AWG	MIL-W-22759	150 °C	14.17 mm	0.558 "	2660	34 AWG	600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated	0.38 mm	0.015 in
TE Connectivity AMP Connectors 82A0811-24-9	24 AWG	MIL-W-22759		0.94 mm	0.037 in	105	56 AWG	600 V	Copper Tinned	White	Hook-Up	Ethylene Tetrafluoroethylene (ETFE)		0.09 mm	-65 ░C	200 °C	0.004 in
TE Connectivity AMP Connectors 82A0811-0-9CS3193-L079	44 AWG	MIL-W-22759	150 °C	14.17 mm	0.558 "	2660	34 AWG	600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated	0.38 mm	0.015 in
TE Connectivity AMP Connectors 82A0811-22-9	22 AWG	MIL-W-22759	150 °C	1.37 mm	0.054 in			600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated		0.09 mm			0.004 in	154	44
TE Connectivity AMP Connectors 82A0811-0-9CS3193	44 AWG	MIL-W-22759	150 °C	14.17 mm	0.558 "	2660	34 AWG	600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated	0.38 mm	0.015 in
TE Connectivity AMP Connectors 82A0811-8-9-F874	8 AWG	MIL-W-22759	150 °C	5.84 mm	0.23 in	665		600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated		0.3 mm			0.012 in			36
TE Connectivity AMP Connectors 82A0811-000-9		MIL-W-22759	150 °C	17.22 mm	0.678 in	4123		600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated	0.38 mm	0.015 in							34
TE Connectivity AMP Connectors 82A0811-8-4	8 AWG	MIL-W-22759	150 °C	5.84 mm	0.23 in	665		600 V	Copper Tinned	Yellow	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated		0.3 mm			0.012 in			36
TE Connectivity AMP Connectors 82A0811-2-9CS3193	2 AWG	MIL-W-22759	150 °C			1665	34 AWG	600 V	Copper Tinned	White	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated	0.38 mm	0.015 in								11 mm	0.433 "
TE Connectivity AMP Connectors 82A0811-8-2	8 AWG	MIL-W-22759	150 °C	5.84 mm	0.23 in	665		600 V	Copper Tinned	Red	Hook-Up Dual Wall	Ethylene Tetrafluoroethylene (ETFE) Irradiated		0.3 mm			0.012 in			36
