PIN HEADER, BOARD-TO-BOARD, 2 MM, 2 ROWS, 12 CONTACTS, THROUGH HOLE, M22 SERIES

Part	Mated Stacking Heights	Insulation Material	Pitch - Mating	Pitch - Mating	Mounting Type	Insulation Color	Contact Material	Contact Shape	Connector Type	Material Flammability Rating	Contact Length - Post [x]	Contact Length - Post	Current Rating (Amps)	Fastening Type	Insulation Height	Insulation Height	Number of Rows [custom]	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Row Spacing - Mating	Row Spacing - Mating	Number of Positions	Termination	Contact Finish - Mating	Contact Length - Mating	Contact Length - Mating	Contact Type	Shrouding	Overall Contact Length	Overall Contact Length	Contact Finish - Post
Harwin Inc. M22-2520605	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	12	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2521046	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	20	Solder		3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in	Tin
Harwin Inc. M22-2521546	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	30	Solder		3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in	Tin
Harwin Inc. M22-2521005	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	20	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2521205	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	24	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2520846	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	16	Solder		3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in	Tin
Harwin Inc. M22-2520205	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	4	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2520505	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	10	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2520305	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	6	Solder	Gold	3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in
Harwin Inc. M22-2520546	3.8 mm 5.9 mm 8.6 mm	Nylon 6T Polyamide (PA6T)	0.079 "	2 mm	Through Hole	Black	Phosphor Bronze	Square	Header Cuttable	UL94 V-0	0.091 "	2.3 mm	1 A	Push-Pull	0.059 in	1.5 mm	2	All	-40 C	105 ░C	2 mm	0.079 in	10	Solder		3.5 mm	0.138 in	Male Pin	Unshrouded	7.3 mm	0.287 in	Tin
