5449 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 9COND 14AWG BLACK 1000'
| Part | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Cable Type | Usage | Conductor Material | Jacket (Insulation) Material | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Insulation | Number of Conductors | Length | Length | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Black | 0.634 in | 16.1 mm | Biological Compatibility Rip Cord | Multi-Conductor | Communication Control | Copper Tinned | Poly-Vinyl Chloride (PVC) | -30 ░C | 105 ░C | Poly-Vinyl Chloride (PVC) | 9 | 304.8 m | 1000 ft | 41 | 30 | 600 V | 1.6 mm | 0.063 in | 14.5 AWG | ISO 10993 UL Style 2501 |
 ALPHA WIRE | Slate | 0.634 in | 16.1 mm | Biological Compatibility Rip Cord | Multi-Conductor | Communication Control | Copper Tinned | Poly-Vinyl Chloride (PVC) | -30 ░C | 105 ░C | Poly-Vinyl Chloride (PVC) | 9 | 41 | 30 | 600 V | 1.6 mm | 0.063 in | 14.5 AWG | ISO 10993 UL Style 2501 |
