626-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 9POS R/A SOLDER
| Part | Contact Material | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Backset Spacing | Backset Spacing | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Number of Positions | Contact Finish | Material Flammability Rating | Number of Rows [custom] | Connector Type | Connector Style | Termination | Current Rating (Amps) | Features | Flange Feature | Mounting Type | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.38 µm | 15 µin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | Housing/Shell (M3) | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Mounting Brackets Shielded | 4-40 | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Mounting Brackets Shielded | 4-40 Mating Side Female Screwlock | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | Housing/Shell (Unthreaded) | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.76 Ám | 30 Áin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | Housing/Shell (M3) | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 85 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.38 µm | 15 µin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | 4-40 Mating Side Female Screwlock | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | Housing/Shell (M3) | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 85 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.38 µm | 15 µin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | 4-40 | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.76 Ám | 30 Áin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | Housing/Shell | Board Edge Right Angle Through Hole | 4-40 | |
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | Black | -55 C | 125 °C | 1 | DE E | Signal | 0.584 " | 14.84 mm | 0.38 µm | 15 µin | Nickel Plated Steel | 9 | Gold | UL94 V-0 | 2 | Receptacle Female Sockets | D-Sub | Solder | 3 A | Board Lock Mounting Brackets Shielded | 4-40 | Board Edge Right Angle Through Hole |
