UCC3801 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC REG CTRLR MULT TOPOLOGY 8SOIC
| Part | Mounting Type | Duty Cycle (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Supplier Device Package | Output Configuration | Synchronous Rectifier | Control Features | Output Type | Function | Package / Case | Package / Case | Package / Case | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Number of Outputs | Frequency - Switching | Clock Sync | Topology | Output Phases |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Surface Mount | 49 % | 0 °C | 70 °C | 8-SOIC | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 0.154 in | 8-SOIC | 3.9 mm | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||
Texas Instruments | Surface Mount | 49 % | 0 °C | 70 °C | 8-SOIC | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 0.154 in | 8-SOIC | 3.9 mm | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||
Texas Instruments | Surface Mount | 49 % | 0 °C | 70 °C | 8-SOIC | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 0.154 in | 8-SOIC | 3.9 mm | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||
 Texas Instruments | Through Hole | 49 % | 0 °C | 70 °C | 8-PDIP | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 8-DIP (0.300" 7.62mm) | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||||
 Texas Instruments | Surface Mount | 49 % | 0 °C | 70 °C | 8-TSSOP | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 0.173 in | 8-TSSOP | 4.4 mm | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||
 Texas Instruments | Surface Mount | 49 % | 0 °C | 70 °C | 8-TSSOP | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 0.173 in | 8-TSSOP | 4.4 mm | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 | ||
Texas Instruments | Through Hole | 49 % | 0 °C | 70 °C | 8-PDIP | Positive | Frequency Control | Transistor Driver | Step-Down Step-Up Step-Up/Step-Down | 8-DIP (0.300" 7.62mm) | 12 V | 7.4 V | 1 | 46 kHz | Boost Buck Flyback Forward Converter | 1 |
