WR-120S Series

Catalog

CONN RCPT 120POS SMD GOLD

Part	Mated Stacking Heights	Contact Finish Thickness	Contact Finish Thickness	Pitch	Pitch	Features	Mounting Type	Number of Positions	Contact Finish	Height Above Board	Height Above Board [z]	Connector Type	Number of Rows [custom]	Height Above Board	Height Above Board [z]
JAE Electronics WR-120SB-VFH30-N1-R1000	7 mm 8 mm 9 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm	Board Guide	Surface Mount	120	Gold	6.25 mm	0.246 in	Receptacle Center Strip Contacts	2
JAE Electronics WR-120S-VF-N1-R1500	4 mm 5 mm 6 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm		Surface Mount	120	Gold	3.25 mm		Receptacle Center Strip Contacts	2	0.128 in
JAE Electronics WR-120SB-VF-N1-R1500	4 mm 5 mm 6 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm	Board Guide	Surface Mount	120	Gold	3.25 mm		Receptacle Center Strip Contacts	2	0.128 in
JAE Electronics WR-120S-VFH05-N1-R1500	4.5 mm 5.5 mm 6.5 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm		Surface Mount	120	Gold		0.148 in	Receptacle Center Strip Contacts	2		3.75 mm
JAE Electronics WR-120S-VFH30-N1-R1000	7 mm 8 mm 9 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm		Surface Mount	120	Gold	6.25 mm	0.246 in	Receptacle Center Strip Contacts	2
JAE Electronics WR-120S-VFH05-N1	4.5 mm 5.5 mm 6.5 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm		Surface Mount	120	Gold		0.148 in	Receptacle Center Strip Contacts	2		3.75 mm
JAE Electronics WR-120SB-VFH30-N1-C100	7 mm 8 mm 9 mm	0.1 Ám	4 Áin	0.02 "	0.5 mm	Board Guide	Surface Mount	120	Gold	6.25 mm	0.246 in	Receptacle Center Strip Contacts	2
