2200/22 Series

Catalog

HOOK-UP STRND 22AWG GRY

Part	Qualification	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Conductor Material	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge	Ratings	Length	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Strand	Length [x]	Length [x]
Daburn Electronics 2200/22GY-1000	MIL-W-16878 Type B	Abrasion Resistant	0.051 in	1.3 mm	Gray	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up	30 AWG	7
Daburn Electronics 2200/22SBR-1000	MIL-W-16878 Type B	Abrasion Resistant	0.054 in	1.37 mm	Brown	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up			Solid
Daburn Electronics 2200/22SRD-1000	MIL-W-16878 Type B	Abrasion Resistant	0.054 in	1.37 mm	Red	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up			Solid
Daburn Electronics 2200/22SYL-100	MIL-W-16878 Type B	Abrasion Resistant	0.054 in	1.37 mm	Yellow	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429			0.25 mm	0.01 in	600 V	Hook-Up			Solid	100 ft	30.5 m
Daburn Electronics 2200/22OR-100	MIL-W-16878 Type B	Abrasion Resistant	0.051 in	1.3 mm	Orange	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429			0.25 mm	0.01 in	600 V	Hook-Up	30 AWG	7		100 ft	30.5 m
Daburn Electronics 2200/22SVI-1000	MIL-W-16878 Type B	Abrasion Resistant	0.054 in	1.37 mm	Violet	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up			Solid
Daburn Electronics 2200/22SGR-1000	MIL-W-16878 Type B	Abrasion Resistant	0.054 in	1.37 mm	Green	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up			Solid
Daburn Electronics 2200/22VI-1000	MIL-W-16878 Type B	Abrasion Resistant	0.051 in	1.3 mm	Violet	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up	30 AWG	7
Daburn Electronics 2200/22OR-1000	MIL-W-16878 Type B	Abrasion Resistant	0.051 in	1.3 mm	Orange	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429	304.8 m	1000 ft	0.25 mm	0.01 in	600 V	Hook-Up	30 AWG	7
Daburn Electronics 2200/22GR-100	MIL-W-16878 Type B	Abrasion Resistant	0.051 in	1.3 mm	Green	Copper Tinned	Poly-Vinyl Chloride (XLPVC)	-55 C	105 ░C	22 AWG	UL Style 1429			0.25 mm	0.01 in	600 V	Hook-Up	30 AWG	7		100 ft	30.5 m
