J80026 Series

Catalog

CU-CN M12D-CP SCT FIELD C5 D5-8

Part	Applications	Mounting Type	Ingress Protection	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Cable Opening [Max]	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Min]	Current Rating (Amps)	Primary Material	Shielding	Insert Material [custom]	Insert Material [custom]	Termination	Voltage Rating	Shell Material	Orientation	Fastening Type	Contact Finish - Mating	Color	Contact Material	Shell Finish	Material Flammability Rating	Features	Shell Size - Insert	Backshell Material, Plating	Cable Opening [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Orientation [x]
Telegartner Inc 100007500	Industrial	Free Hanging (In-Line)	IP67 - Dust Tight Waterproof	Receptacle Male Pins	85 °C	-40 C	4	0.315 in	8 mm	5 mm	0.197 in	4 A	Metal	Shielded	Nylon	Polyamide (PA)	Screw	250 V	Brass and Zinc Die Cast	D	Threaded	Gold	Silver	Brass	Nickel	UL94 HB	Backshell	M12-4	Brass and Zinc Die Cast Nickel
Telegartner Inc 100007501	Industrial	Free Hanging (In-Line)	IP67 - Dust Tight Waterproof	Receptacle Male Pins	85 °C	-40 C	4	0.354 in		5 mm	0.197 in	4 A	Metal	Unshielded	Nylon	Polyamide (PA)	IDC	250 VAC	Brass	D	Threaded	Gold	Silver	Brass	Nickel	UL94 V-0	Backshell	M12-4	Brass Nickel	9 mm
Telegartner Inc 100007499	Industrial	Free Hanging (In-Line)	IP67 - Dust Tight Waterproof	Receptacle Male Pins	85 °C	-40 C	8	0.354 in		5.5 mm	0.217 in	0.5 A	Metal	Shielded	Nylon	Polyamide (PA)	IDC	50 VAC 60 VDC	Brass and Zinc Die Cast		Threaded	Gold	Silver	Brass	Nickel	UL94 V-0	Backshell	M12-8	Brass and Zinc Die Cast Nickel	9 mm	31.5 µin	0.8 µm	X
