633-M15 Series
Manufacturer: EDAC Inc.
Catalog
633M SERIES RIGHT ANGLE D-SUB PL
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Color | Connector Type | Contact Finish | Features | Material Flammability Rating | Number of Rows [custom] | Current Rating (Amps) | Connector Style | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Material, Finish | Flange Feature | Flange Feature | Mounting Type | Number of Positions | Contact Type | Backset Spacing | Backset Spacing | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | White | Plug Male Pins | Gold | Board Lock Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Nickel Plated Steel | Housing/Shell | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | Flash | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Nickel Plated Steel | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Nickel Plated Steel | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | White | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Housing/Shell | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | White | Plug Male Pins | Gold | Board Lock Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Housing/Shell | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 15 µin | 0.38 µm | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | White | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 15 µin | 0.38 µm | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | Flash | ||||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Nickel Plated Steel | Board Side (4-40) | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Nickel Plated Steel | Housing/Shell | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 30 Áin | 0.76 Ám | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyamide (PA6T) Nylon 6T | White | Plug Male Pins | Gold | Grounding Indents Shielded | UL94 V-0 | 3 | 5 A | D-Sub High Density | (DE E) High Density | 1 | Housing/Shell | 4-40 | Board Edge Right Angle Through Hole | 15 | Signal | 8.89 mm | 0.35 in | Solder | 15 µin | 0.38 µm |
