FD4D002 Series
Manufacturer: Belden Inc.
Beta
⌘K
CBL FIBER OPTIC 125UM MULTIMODE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Core Diameter [diameter] | Features | Ratings | Cladding Diameter [diameter] | Jacket (Insulation) Material | Style | Type | Tensile Strength |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 70 °C | -40 C | 4.67 mm | 0.184 in | Aqua | 50 µm | 2 Fibers Rip Cord | OFNR | 125 µm | Low Smoke Zero Halogen (LSZH) | Multiple Fibers | Multimode | 20.4 kg |
 Belden Inc. | 70 °C | -40 C | 4.67 mm | 0.184 in | Black | 50 µm | 2 Fibers Rip Cord | OFNR | 125 µm | Low Smoke Zero Halogen (LSZH) | Multiple Fibers | Multimode | 20.4 kg |
Belden Inc. | 70 °C | -40 C | 4.42 mm | 0.174 in | Black | 50 µm | 2 Fibers Rip Cord | OFNP | 125 µm | Poly-Vinyl Chloride (PVC) | Multiple Fibers | Multimode | 20.4 kg |
Belden Inc. | 70 °C | -40 C | 4.67 mm | 0.184 in | Black | 50 µm | 2 Fibers Rip Cord | OFNR | 125 µm | Poly-Vinyl Chloride (PVC) | Multiple Fibers | Multimode | 20.4 kg |
