857 Series
Manufacturer: EDAC Inc.
Catalog
STANDARD CARD EDGE CONNECTORS HIGH TEMP CARD EDGE CONNECTOR
...
| Part | Termination Rows | Material - Insulation | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Contact Type | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Termination | Card Thickness [Max] | Card Thickness [Min] | Gender | Card Type | Read Out | Number of Rows | Number of Positions | Contact Finish | Pitch | Pitch | Contact Material | Number of Rows [custom] | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | 26 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Single Edge | Single | 1 | 26 | Gold | 3.96 mm | 0.156 in | Copper Alloy | ||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 19 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 38 | Tin | 3.96 mm | 0.156 in | Copper Alloy | 2 | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 26 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 52 | Tin | 3.96 mm | 0.156 in | Copper Alloy | 2 | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount M3 Threaded Insert Top Opening | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Single Edge | Single | 1 | Gold | 3.96 mm | 0.156 in | Copper Alloy | 17 | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | Semi Bellows | Right Angle Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | 9 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 18 | Gold | 3.96 mm | 0.156 in | Copper Alloy | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | Semi Bellows | Right Angle Through Hole | 125 °C | -40 C | 32 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 64 | Tin | 3.96 mm | 0.156 in | Copper Alloy | 2 | ||||||
 EDAC Inc. | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Black | Semi Bellows | Board Edge Straddle Mount | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 42 | Tin | 3.96 mm | 0.156 in | Copper Alloy | 2 | 21 | Card Extender | |||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 20 Bay/Row | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Single Edge | Single | 1 | 20 | Tin | 3.96 mm | 0.156 in | Copper Alloy | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 4-40 Flush Mount Threaded Insert Top Opening | Black | Semi Bellows | Right Angle Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | 16 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Single Edge | Single | 1 | 16 | Gold | 3.96 mm | 0.156 in | Copper Alloy | ||||||
 EDAC Inc. | Black | Semi Bellows | Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | 20 Bay/Row | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Dual | 40 | Gold | 3.96 mm | 0.156 in | Copper Alloy | 2 |
