LSH1-04 Series
Manufacturer: New Energy
Beta
⌘K
LED MOD XHP50.2 WH LNR STR 3000K
| Part | Type | CCT (K) | CCT (K) | Lens Type | Size / Dimension [x] | Size / Dimension [y] | Voltage - Forward (Vf) (Typ) | Lumens/Watt @ Current - Test | CRI (Color Rendering Index) | Temperature - Test | Color | Current - Max [Max] | Configuration | Luminous Flux @ Current/Temperature | Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 New Energy | LED Module | 3000 K | 5-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 132 lm/W | 70 | 85 °C | Warm White | 1.5 A | Linear Light Strip | ||
New Energy | LED Module | 4000 K | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 70 | 85 °C | Neutral White | 1.5 A | Linear Light Strip | |||
New Energy | LED Module | 4000 K | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 80 | 85 °C | Neutral White | 1.5 A | Linear Light Strip | 4480 lm | 1.52 mm | |
New Energy | LED Module | 3000 K | 5-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 133 lm/W | 80 | 85 °C | Warm White | 1.5 A | Linear Light Strip | 4160 lm | 1.52 mm |
New Energy | LED Module | 5700 K | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 70 | 85 °C | Cool White | 1.5 A | Linear Light Strip | |||
New Energy | LED Module | 5700 K | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 80 | 85 °C | Cool White | 1.5 A | Linear Light Strip | 4480 lm | 1.52 mm | |
New Energy | LED Module | 2700 K | 3-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 115 lm/W | 80 | 85 °C | Warm White | 1.5 A | Linear Light Strip | 3600 lm | |
New Energy | LED Module | 5000 K | 5-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 70 | 85 °C | Cool White | 1.5 A | Linear Light Strip | ||
New Energy | LED Module | 2700 K | 3-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 115 lm/W | 90 | 85 °C | Warm White | 1.5 A | Linear Light Strip | 3600 lm | 1.52 mm |
New Energy | LED Module | 5000 K | 5-Step MacAdam Ellipse | Domed | 6.7 " | 32.99 mm | 44.8 V | 143 lm/W | 80 | 85 °C | Cool White | 1.5 A | Linear Light Strip | 4480 lm | 1.52 mm |
