3314H Series
Manufacturer: Bourns Inc.
Beta
⌘K
TRIMMER, SINGLE TURN, CERMET, TOP ADJUST, 50 KOHM, SURFACE MOUNT, 1 TURNS
| Part | Resistive Material | Temperature Coefficient | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension | Size / Dimension [y] | Size / Dimension [x] | Power (Watts) | Power (Watts) | Adjustment Type | Resistance | Tolerance | Mounting Type | Number of Turns | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 50000 Ohms | 20 % | Through Hole | 1 | PC Pins |
 Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 10000 Ohms | 20 % | Through Hole | 1 | PC Pins |
Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 50 Ohms | 20 % | Through Hole | 1 | PC Pins |
Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 10 Ohms | 20 % | Through Hole | 1 | PC Pins |
Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 2 MOhms | 20 % | Through Hole | 1 | PC Pins |
Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 100 Ohms | 20 % | Through Hole | 1 | PC Pins |
 Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 20 Ohms | 20 % | Through Hole | 1 | PC Pins |
Bourns Inc. | Cermet | 100 ppm/°C | 0.177 " | 0.177 in | Face | 4.5 mm | 4.5 mm | 0.25 W | 0.25 W | Top Adjustment | 250000 Ohms | 20 % | Through Hole | 1 | PC Pins |
