325-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 17POS 0.100
| Part | Termination Rows | Material - Insulation | Card Thickness | Card Thickness | Contact Type | Pitch | Pitch | Contact Finish | Number of Positions/Bay/Row [custom] | Card Type | Mounting Type | Color | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Read Out | Contact Material | Number of Rows | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | 4-40 Flush Mount Threaded Insert Top Opening | Single | Copper Alloy | 1 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | Single | Copper Alloy | 1 | Solder | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | Single | Copper Alloy | 1 | Solder | 0.25 Ám | 10 Áin | |||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | Single | Copper Alloy | 1 | Wire Wrap | 0.25 Ám | 10 Áin | ||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | Single | Copper Alloy | 1 | Wire Wrap | 0.25 Ám | 10 Áin | 0.16 " | 4.06 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Cantilever | 0.1 " | 2.54 mm | Gold | 17 | Non Specified - Single Edge | Through Hole | Green | Female | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | Single | Copper Alloy | 1 | Solder Eyelet(s) | 0.25 Ám | 10 Áin |
