807-013 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 26POS 0.156
...
| Part | Material - Insulation | Termination Rows | Card Type | Number of Rows [custom] | Gender | Mounting Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Color | Read Out | Contact Finish | Number of Positions/Bay/Row | Contact Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Dual Edge | 2 | Female | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 26 | Green | Dual | Tin | 13 | Semi Bellows | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Right Angle Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Dual Edge | 2 | Female | Right Angle Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 26 | Green | Dual | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Right Angle Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Dual Edge | 2 | Female | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 26 | Green | Dual | Gold | 13 | Semi Bellows | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Female | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | 13 | Green | Single | Tin | 13 | Semi Bellows | 3.96 mm | 0.156 in | 1 | Flush Mount M3 Threaded Insert Top Opening |
