PBC27 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER VERT 27POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Mating	Contact Shape	Contact Material	Shrouding	Overall Contact Length [x]	Overall Contact Length [x]	Contact Length - Mating	Contact Length - Mating	Material Flammability Rating	Contact Length - Post	Contact Length - Post	Insulation Material	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Contact Type	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows	Termination	Pitch - Mating	Pitch - Mating	Number of Positions	Connector Type	Insulation Height	Insulation Height	Contact Finish - Post	Style	Mounting Type	Number of Positions Loaded	Fastening Type	Contact Length - Post [custom]	Contact Length - Post [custom]	Insulation Height [z]	Insulation Height [z]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Overall Contact Length	Overall Contact Length
Sullins Connector Solutions PBC27SADN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded	19.05 mm	0.75 in	0.23 in	5.84 mm	UL94 V-0	10.67 mm	0.42 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin	1	Solder	0.1 "	2.54 mm	27	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull
Sullins Connector Solutions PBC27DBBN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.23 in	5.84 mm	UL94 V-0			Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway			Tin	Board to Board Cable	Right Angle Through Hole	All	Push-Pull	5.08 mm	0.2 "	6.1 mm	0.24 in	0.1 in	2.54 mm	2
Sullins Connector Solutions PBC27SBDN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.23 in	5.84 mm	UL94 V-0	10.16 mm	0.4 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin	1	Solder	0.1 "	2.54 mm	27	Header Breakaway	0.14 in	3.56 mm	Tin	Board to Board Cable	Right Angle Through Hole	All	Push-Pull
Sullins Connector Solutions PBC27DACN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.23 in	5.84 mm	UL94 V-0	8.13 mm	0.32 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull					0.1 in	2.54 mm	2	16.51 mm	0.65 in
Sullins Connector Solutions PBC27DFBN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.318 in	8.08 mm	UL94 V-0	5.58 mm	0.22 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull					0.1 in	2.54 mm	2	16.21 mm	0.638 in
Sullins Connector Solutions PBC27SAHN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.23 in	5.84 mm	UL94 V-0	20.83 mm	0.82 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin	1	Solder	0.1 "	2.54 mm	27	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull								29.21 mm	1.15 in
Sullins Connector Solutions PBC27SBEN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.23 in	5.84 mm	UL94 V-0	12.7 mm	0.5 "	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin	1	Solder	0.1 "	2.54 mm	27	Header Breakaway	0.14 in	3.56 mm	Tin	Board to Board Cable	Right Angle Through Hole	All	Push-Pull
Sullins Connector Solutions PBC27DFEN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.318 in	8.08 mm	UL94 V-0	13.21 mm	0.52 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull					0.1 in	2.54 mm	2	23.83 mm	0.938 in
Sullins Connector Solutions PBC27DGAN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.318 in	8.08 mm	UL94 V-0	2.54 mm	0.1 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway			Tin	Board to Board Cable	Right Angle Through Hole	All	Push-Pull			6.1 mm	0.24 in	0.1 in	2.54 mm	2
Sullins Connector Solutions PBC27DFDN	2.54 µm	100 µin	Gold	Square	Phosphor Bronze	Unshrouded			0.318 in	8.08 mm	UL94 V-0	10.67 mm	0.42 in	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	3 A	Male Pin	Black	0.25 µm	10 µin		Solder	0.1 "	2.54 mm	54	Header Breakaway	0.1 in	2.54 mm	Tin	Board to Board Cable	Through Hole	All	Push-Pull					0.1 in	2.54 mm	2	21.29 mm	0.838 in
