DML-06 Series

Manufacturer: Adam Tech

Catalog

CONN HEADER R/A 6POS 3MM

Part	Connector Type	Voltage Rating	Contact Material	Number of Positions Loaded	Mounting Type	Contact Shape	Contact Type	Insulation Height	Insulation Height	Insulation Color	Number of Rows [custom]	Row Spacing - Mating	Row Spacing - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Material	Features	Current Rating (Amps)	Style	Number of Positions	Material Flammability Rating	Fastening Type	Pitch - Mating	Pitch - Mating	Termination	Shrouding	Contact Finish - Post	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Insulation Height [z]	Insulation Height [z]
Adam Tech DML-06-A-H-T-A-SBL	Header	250 V	Brass	All	Right Angle Through Hole	Square	Male Pin	0.29 in	7.37 mm	Black	2	0.118 in	3 mm	0.126 "	3.2 mm	Thermoplastic	Board Lock	Varies by Wire Gauge	Board to Cable/Wire	6	UL94 V-0	Locking Ramp	3 mm	0.118 in	Solder	Shrouded - 4 Wall	Tin
Adam Tech DML-06-A-V-T-SMT-BL-PP-T/R	Header	250 VAC	Brass	All	Surface Mount	Square	Male Pin			Black	2	0.118 in	3 mm			Thermoplastic	Board Lock		Board to Cable/Wire	6	UL94 V-0	Locking Ramp	3 mm	0.118 in	Solder	Shrouded - 4 Wall	Tin	85 °C	-25 °C	5 A	0.39 in	9.91 mm
