MMI-M1FSG Series
Manufacturer: Adam Tech
Beta
⌘K
CONN RCPT FMALE 2P GOLD SLDR CUP
| Part | Color | Shell Finish | Contact Finish - Mating | Voltage Rating | Contact Material | Number of Positions | Mounting Feature | Shell Material | Insert Material | Shielding | Fastening Type | Ingress Protection | Mounting Type | Connector Type | Orientation [custom] | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Primary Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | Silver | Chrome | Gold | 300 VDC | Brass | 2 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 9 A | -55 C | 150 °C | Metal |
 Adam Tech | Silver | Chrome | Gold | 300 VDC | Brass | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 9 A | -55 C | 150 °C | Metal | |
 Adam Tech | Silver | Chrome | Gold | 200 V | Brass | 6 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 5 A | -55 C | 150 °C | Metal |
 Adam Tech | Silver | Chrome | Gold | 200 V | Brass | 8 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 5 A | -55 C | 150 °C | Metal |
 Adam Tech | Silver | Chrome | Gold | 250 V | Brass | 4 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 8 A | -55 C | 150 °C | Metal |
 Adam Tech | Silver | Chrome | Gold | 250 V | Brass | 5 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 7 A | -55 C | 150 °C | Metal |
 Adam Tech | Silver | Chrome | Gold | 200 V | Brass | 10 | Bulkhead - Rear Side Nut | Brass | Polyphenylene Sulfide (PPS) | Unshielded | Push-Pull | IP50 - Dust Protected | Panel Mount | Receptacle Female Sockets | G | 2 A | -55 C | 150 °C | Metal |
