MC74HC10A Series

Triple 3-Input NAND Gate

Catalog

Triple 3-Input NAND Gate

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Logic Type	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Number of Circuits	Current - Quiescent (Max) [Max]	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Max Propagation Delay @ V, Max CL	Number of Inputs	Input Logic Level - High [Min]	Input Logic Level - High [Max]	Mounting Type	Package / Case [x]	Package / Case [y]	Package / Case	Supplier Device Package	Package / Case [custom]	Package / Case [custom]
ON Semiconductor MC74HC10FL2	2 V	6 V	NAND Gate	5.2 mA	5.2 mA	3	1 çA	1.8 V	0.5 V	-55 °C	125 °C	16 ns	3	1.5 V	4.2 V
ON Semiconductor MC74HC10ADR2G	2 V	6 V	NAND Gate	5.2 mA	5.2 mA	3	1 çA	1.8 V	0.5 V	-55 °C	125 °C	16 ns	3	1.5 V	4.2 V	Surface Mount	0.154 in	3.9 mm	14-SOIC
ON Semiconductor MC74HC10ADTR2G	2 V	6 V	NAND Gate	5.2 mA	5.2 mA	3	1 çA	1.8 V	0.5 V	-55 °C	125 °C	16 ns	3	1.5 V	4.2 V	Surface Mount			14-TSSOP	14-TSSOP	0.173 "	4.4 mm

Catalog

Triple 3-Input NAND Gate

Key Features

• Output Drive Capability: 10 LSTTL Loads

• Outputs Directly Interface to CMOS, NMOS and TTL

• Operating Voltage Range: 2 to 6 V

• Low Input Current: 1 µA

• High Noise Immunity Characteristic of CMOS Devices

• In Compliance With the Requirements Defined JEDEC Standard No. 7 A

• Chip Complexity: 36 FETs or 9 Equivalent Gates

• PbFree Packages are Available

Description

The MC74HC10A is identical in pinout to the LS10. The device inputs are compatible with Standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs.
