82760 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 18AWG NATURAL 1000'
| Part | Shield Coverage | Shield Material | Features | Number of Conductors | Length | Length | Conductor Material | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Voltage | Jacket Color | Shield Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Insulation | Jacket (Insulation) Material | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Drain Wire | 2 | 304.8 m | 1000 ft | Copper Tinned | Multi-Conductor | 0.014 in | 0.356 mm | 300 VDC | Natural | Foil | 3.71 mm | 0.146 in | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 30 AWG | 19 | 18 AWG |
 Belden Inc. | 100 % | Aluminum | Drain Wire | 2 | 152.4 m | 500 ft | Copper Tinned | Multi-Conductor | 0.014 in | 0.356 mm | 300 VDC | Natural | Foil | 3.71 mm | 0.146 in | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 30 AWG | 19 | 18 AWG |
