626-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONNECTOR,D-SHELL,PCB MOUNT,PLUG,25 CONTACTS,SKT,0.109 PITCH,PC TAIL TERMINAL,HOLE .115-.125 ROHS COMPLIANT: YES
| Part | Color | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Number of Rows [custom] | Connector Style | Features | Current Rating (Amps) | Contact Type | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Backset Spacing | Backset Spacing | Contact Finish Thickness | Flange Feature | Contact Finish | Connector Type | Shell Material, Finish | Termination | Material Flammability Rating | Mounting Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Flash | Housing/Shell (Unthreaded) | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | |||
 EDAC Inc. | Black | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Flash | 4-40 | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | |||
 EDAC Inc. | Black | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | 4-40 Mating Side Female Screwlock | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Black | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Flash | Housing/Shell (Unthreaded) | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | |||
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Flash | Housing/Shell (M3) | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | |||
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Housing/Shell | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | 30 Áin | 0.76 Ám | 4-40 | |
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Flash | 4-40 | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | |||
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Housing/Shell (M3) | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | 15 µin | 0.38 µm | ||
 EDAC Inc. | Black | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | 4-40 Mating Side Female Screwlock | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | 15 µin | 0.38 µm | ||
 EDAC Inc. | Black | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | 2 | D-Sub | Board Lock Mounting Brackets Shielded | 3 A | Signal | B DB | 3 | 0.584 " | 14.84 mm | Housing/Shell (Unthreaded) | Gold | Receptacle Female Sockets | Nickel Plated Steel | Solder | UL94 V-0 | Board Edge Right Angle Through Hole | 25 | 30 Áin | 0.76 Ám |
