146494 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HDR 70POS 0.1 STACK T/H

Part	Mounting Type	Length - Post (Mating) [x]	Length - Post (Mating) [x]	Pitch [x]	Pitch [x]	Termination	Row Spacing [x]	Row Spacing	Contact Finish - Post (Mating)	Length - Overall Pin [x]	Length - Overall Pin [x]	Contact Finish Thickness - Post (Mating)	Contact Finish Thickness - Post (Mating)	Number of Rows	Length - Stack Height [x]	Length - Stack Height [x]	Number of Positions	Color	Length - Tail [x]	Length - Tail [x]
TE Connectivity Raychem Cable Protection 8-146494-5	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	70	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 5-146494-1	Through Hole	0.33 in	8.382 mm			Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	2	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 7-146494-2	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	44	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 6-146494-9	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	38	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 7-146494-9	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	58	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 8-146494-9	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	78	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 5-146494-3	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	6	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 6-146494-5	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	30	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 7-146494-5	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	50	Black	0.1 "	2.54 mm
TE Connectivity Raychem Cable Protection 7-146494-8	Through Hole	0.33 in	8.382 mm	2.54 mm	0.1 in	Solder	0.1 in	2.54 mm	Gold	0.93 in	23.622 mm	0.38 Ám	15 Áin	2	0.5 in	12.7 mm	56	Black	0.1 "	2.54 mm
