IGBT Module - Sixpack E3-Pack
Description
AI
The Converter + Brake + Inverter series utilizes rugged input rectifier diodes and short circuit rated XPT igbts in combination with fast switching SONIC free wheeling diodes.
Beta
⌘K
IGBT Module - Sixpack E3-Pack
IGBT Module - Sixpack E3-Pack
| Part | Power - Max [Max] | Voltage - Collector Emitter Breakdown (Max) [Max] | Vce(on) (Max) @ Vge, Ic | Current - Collector (Ic) (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Input | Supplier Device Package | NTC Thermistor | Package / Case | Current - Collector Cutoff (Max) [Max] | IGBT Type | Mounting Type | Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | 390 W | 1200 V | 2.2 V | 120 A | -40 °C | 150 °C | Standard | V1A-PAK | V1A-PAK | 200 µA | PT | Chassis Mount | Single | |
 LITTELFUSE | 390 W | 1200 V | 2.2 V | 120 A | -40 C | 125 °C | Three Phase Bridge Rectifier | E3 | E3 | 200 µA | PT | Chassis Mount | Three Phase Inverter with Brake | |
LITTELFUSE | 390 W | 1200 V | 2.2 V | 120 A | -40 C | 125 °C | Standard | E3 | E3 | 200 µA | PT | Chassis Mount | Three Phase Inverter with Brake |
