SWS600L Series
Manufacturer: TDK Corporation
Beta
⌘K
AC/DC OPEN FRAME POWER SUPPLY (PSU), 1 OUTPUT, 645W, 85V AC TO 265V AC, ADJUSTABLE, FIXED, 15 V
| Part | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Current - Output 1 | Number of Outputs | Voltage - Output 1 | Features | Power (Watts) | Type | Applications | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Mounting Type | Voltage - Isolation | Efficiency | Voltage - Output 1 [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 7.48 in | 190 mm | 119.9 mm | 2.4 in | 61 mm | 4.72 in | 43 A | 1 | 15 V | Adjustable Output Load Sharing PFC Remote On/Off Remote Sense Universal Input | 600 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | ||
 TDK Corporation | 7.48 in | 190 mm | 119.9 mm | 3.62 in | 91.9 mm | 4.72 in | 27 A | 1 | 24 V | Adjustable Output PFC Standby Output Universal Input | 648 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 84 % | |
TDK Corporation | 7.48 in | 190 mm | 61 mm | 4.72 in | 120 mm | 2.4 in | 120 A | 1 | 5 V | Adjustable Output Load Sharing PFC Remote On/Off Remote Sense Universal Input | 600 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 77 % | |
 TDK Corporation | 7.48 in | 190 mm | 119.9 mm | 2.4 in | 61 mm | 4.72 in | 10 A | 1 | Adjustable Output PFC Universal Input | 600 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 84 % | 60 V | |
TDK Corporation | 7.48 in | 190 mm | 61 mm | 4.72 in | 120 mm | 2.4 in | 27 A | 1 | 24 V | Adjustable Output Load Sharing PFC Remote On/Off Remote Sense Universal Input | 648 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 84 % | |
TDK Corporation | 7.48 in | 190 mm | 61 mm | 4.72 in | 120 mm | 2.4 in | 13 A | 1 | 48 V | Adjustable Output Load Sharing PFC Remote On/Off Remote Sense Universal Input | 624 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 84 % | |
 TDK Corporation | 7.48 in | 190 mm | 119.9 mm | 2.4 in | 61 mm | 4.72 in | 120 A | 1 | 3.3 V | Adjustable Output PFC Universal Input | 600 W | Enclosed | ITE (Commercial) | CE cURus TUV | 265 VAC | 85 VAC | Chassis Mount | 3000 V | 72 % |
