1337426 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN BNC PLUG STR 50 OHM SOLDER
| Part | Insertion Loss | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Voltage Rating | Body Finish | Dielectric Material | Center Contact Plating | Body Material | Includes | Connector Style | Fastening Type | Contact Termination | Frequency - Max [Max] | Impedance | Connector Type | Number of Ports | Shield Termination | Mounting Type | Cable Group | Center Contact Material | Housing Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 0.2 dB | -65 ░C | 165 °C | 500 | 500 V | Nickel | Polytetrafluoroethylene (PTFE) | Gold | Brass | 1 Connector 1 Contact 1 Ferrule | BNC | Bayonet Lock | Crimp | 4 GHz | 50 Ohms | Plug Male Pin | 1 | Crimp | Free Hanging (In-Line) | 141A Belden 9907 RG-58C | Brass | Silver |
