R82IC Series

Manufacturer: KEMET

Catalog

CAP FILM 0.15UF 5% 250VDC RADIAL

Part	Package / Case	Capacitance	Mounting Type	Dielectric Material	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Ratings	Voltage Rating - AC	Termination	Applications	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Voltage Rating - DC	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Height - Seated (Max) [z]
KEMET R82IC3150DQ50J	Radial	0.15 ÁF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	11.1 mm	0.437 in	0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.236 "	7.2 mm	6 mm	250 V	5 %	-55 C	105 ░C
KEMET R82IC2150CK50J	Radial	15000 pF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	6.6 mm	0.26 in	0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.098 in	7.2 mm	2.5 mm	250 V	5 %	-55 C	105 ░C
KEMET R82IC2150Z350J	Radial	15000 pF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	6.6 mm	0.26 in	0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.098 in	7.2 mm	2.5 mm	250 V	5 %	-55 C	105 ░C
KEMET R82IC2220DQ50K	Radial	0.022 µF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)			0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.138 in	7.2 mm	3.5 mm	250 V	10 %	-55 C	105 ░C	0.299 in	7.6 mm
KEMET R82IC3220DQ60K	Radial	0.22 µF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	11.1 mm	0.437 in	0.197 "	5 mm	AEC-Q200	140 V	PC Pins	Automotive	0.283 "	0.236 "	7.2 mm	6 mm	250 V	10 %	-55 C	105 ░C
KEMET R82IC3150AA50K	Radial	0.15 ÁF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	11.1 mm	0.437 in	0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.236 "	7.2 mm	6 mm	250 V	10 %	-55 C	105 ░C
KEMET R82IC3100SH55J	Radial	100000 pF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)			0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.197 "	7.2 mm		250 V	5 %	-55 C	105 ░C		0.398 in	5 mm	10.1 mm
KEMET R82IC2470DQ50K	Radial		Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)			0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.177 "	7.2 mm	4.5 mm	250 V	10 %	-55 C	105 ░C	0.378 "	9.6 mm
KEMET R82IC2220DQ60J	Radial	0.022 µF	Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	6.6 mm	0.26 in	0.197 "	5 mm	AEC-Q200	140 V	PC Pins	Automotive	0.283 "	0.098 in	7.2 mm	2.5 mm	250 V	5 %	-55 C	105 ░C
KEMET R82IC2470Z350K	Radial		Through Hole	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)			0.197 "	5 mm	AEC-Q200	160 V	PC Pins	Automotive	0.283 "	0.177 "	7.2 mm	4.5 mm	250 V	10 %	-55 C	105 ░C	0.378 "	9.6 mm
