ECX-1637B Series

Manufacturer: ECS Inc.

Catalog

CRYSTALS 32.000 MHZ 12 PF ECX-1637B +/-7/10PPM -20 - +70C +/-1 PPM AGING 2016 4-SMD ROHS

Part	Height - Seated (Max) [Max]	Height - Seated (Max)	Frequency Tolerance	Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Load Capacitance	Frequency Stability	Operating Mode	Supplier Device Package [y]	Supplier Device Package [x]	Supplier Device Package [custom]	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	ESR (Equivalent Series Resistance)	Type
ECS Inc. ECS-320-12-37B-7KM-TR3	0.02 in	0.5 mm	7 ppm	32 MHz	-20 ░C	70 °C	Surface Mount	12 pF	10 ppm	Fundamental	1.6	2	4-SMD	4-SMD No Lead	1.6 mm	0.079 in	0.063 "	2 mm	50 Ohms	MHz Crystal
ECS Inc. ECS-320-12-37B-7KM-TR	0.02 in	0.5 mm	7 ppm	32 MHz	-20 ░C	70 °C	Surface Mount	12 pF	10 ppm	Fundamental	1.6	2	4-SMD	4-SMD No Lead	1.6 mm	0.079 in	0.063 "	2 mm	50 Ohms	MHz Crystal
ECS Inc. ECS-500-8-37B-CTN-TR	0.02 in	0.5 mm	10 ppm	50 MHz	-40 C	85 °C	Surface Mount	8 pF	20 ppm	Fundamental	1.6	2	4-SMD	4-SMD No Lead	1.6 mm	0.079 in	0.063 "	2 mm	40 Ohms	MHz Crystal
