THICK FILM RESISTORS - SMD RESA-AS 0603 1K 5% 100MW TC200
| Part | Ratings | Tolerance | Resistance | Features | Temperature Coefficient | Package / Case | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Composition | Power (Watts) | Power (Watts) | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Number of Terminations [custom] | Temperature Coefficient | Size / Dimension [y] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | AEC-Q200 | 5 % | 1000 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 200 ppm/°C | 1608 Metric | 0603 | -55 C | 125 °C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 | |||
 Bourns Inc. | 5 % | 1 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 0805 | -55 C | 155 C | 0.049 " | 2 mm | 0.079 in | Thick Film | 0.125 W | 0.125 W | 0.6 mm | 0.024 in | 2 | ±400ppm/°C | 1.25 mm | 0805 | ||||
 Bourns Inc. | AEC-Q200 | 1 % | 49900 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 0402 (1005 Metric) | -55 C | 155 C | 0.02 in | 1 mm | 0.039 " | Thick Film | 0.063 W | 0.0625 W | 0.37 mm | 0.015 " | 2 | 0.5 mm | 0402 | |||
 Bourns Inc. | 1 % | 2.2 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 1206 (3216 Metric) | -55 C | 155 C | 0.061 in | 3.1 mm | 0.122 " | Thick Film | 0.25 W | 0.25 W | 0.65 mm | 0.026 in | 2 | ±400ppm/°C | 1.55 mm | 1206 | ||||
Bourns Inc. | AEC-Q200 | 1 % | 73.2 kOhms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 1608 Metric | 0603 | -55 C | 125 °C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 | |||
Bourns Inc. | AEC-Q200 | 1 % | 3.32 kOhms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 1608 Metric | 0603 | -55 C | 125 °C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 | |||
 Bourns Inc. | AEC-Q200 | 1 % | 100 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 1608 Metric | 0603 | -55 C | 155 C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 | |||
 Bourns Inc. | 1 % | 2.2 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 1608 Metric | 0603 | -55 C | 155 C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 | ±400ppm/°C | ||||
Bourns Inc. | 1 % | 330 kOhms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 0805 | -55 C | 155 C | 0.049 " | 2 mm | 0.079 in | Thick Film | 0.125 W | 0.125 W | 0.6 mm | 0.024 in | 2 | 1.25 mm | 0805 | ||||
Bourns Inc. | AEC-Q200 | 1 % | 18.7 Ohms | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 100 ppm/°C | 1608 Metric | 0603 | -55 C | 125 °C | 0.031 in | 1.6 mm | 0.8 mm | 0.063 " | Thick Film | 0.1 W | 0.1 W | 0.55 mm | 0.022 in | 2 |
