ERZ-E10 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

VARISTOR 330V 4.5KA DISC 11.5MM

Part	Current - Surge	Varistor Voltage (Max) [Max]	Mounting Type	Varistor Voltage (Min) [Min]	Varistor Voltage (Typ)	Maximum DC Volts [Max]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Capacitance @ Frequency	Number of Circuits	Energy	Maximum AC Volts [Max]	Package / Case [diameter]	Maximum DC Volts
Panasonic Industrial Automation Sales ERZ-E10A331	4.5 kA	363 V	Through Hole	297 V	330 V	270 V	Disc 11.5mm	85 °C	-40 °C	470 pF	1	72 J
Panasonic Industrial Automation Sales ERZ-E10A511CS	4.5 kA	561 V	Through Hole	459 V	510 V	410 V	Disc 11.5mm	85 °C	-40 °C	300 pF	1	117 J	320 V
Panasonic Industrial Automation Sales ERZ-E10A821CS	4.5 kA	902 V	Through Hole	738 V	820 V		Disc	85 °C	-40 °C	230 pF	1	154 J	510 V	12.5 mm	670 V
Panasonic Industrial Automation Sales ERZ-E10E751	4.5 kA	825 V	Through Hole	675 V	750 V	615 V	Disc	85 °C	-40 °C	250 pF	1	140 J	460 V	12.5 mm
Panasonic Industrial Automation Sales ERZ-E10F102	4.5 kA	1.1 kV	Through Hole	900 V	1 kV	825 V	Disc	85 °C	-40 °C	200 pF	1	182 J	625 V	12.5 mm
Panasonic Industrial Automation Sales ERZ-E10E821	4.5 kA	902 V	Through Hole	738 V	820 V		Disc	85 °C	-40 °C	230 pF	1	154 J	510 V	12.5 mm	670 V
Panasonic Industrial Automation Sales ERZ-E10F681	4.5 kA	748 V	Through Hole	612 V	680 V	560 V	Disc	85 °C	-40 °C	260 pF	1	133 J	420 V	12.5 mm
Panasonic Industrial Automation Sales ERZ-E10A431CS	4.5 kA	473 V	Through Hole	387 V	430 V	350 V	Disc 11.5mm	85 °C	-40 °C	350 pF	1	99 J	275 V
Panasonic Industrial Automation Sales ERZ-E10E112	4.5 kA	1.21 kV	Through Hole	990 V	1.1 kV	895 V	Disc	85 °C	-40 °C	180 pF	1	196 J	680 V	12.5 mm
Panasonic Industrial Automation Sales ERZ-E10E331	4.5 kA	363 V	Through Hole	297 V	330 V	270 V	Disc 11.5mm	85 °C	-40 °C	470 pF	1	72 J
