ISOW1412 Series

Catalog

LOW-EMISSIONS, 500-KBPS, REINFORCED ISOLATED RS-485/RS-422 TRANSCEIVER WITH INTEGRATED POWER

Part	Data Rate	Pulse Width Distortion (Max) [Max]	Voltage - Supply [Max]	Voltage - Supply [Min]	Propagation Delay tpLH / tpHL (Max) [Max]	Mounting Type	Common Mode Transient Immunity (Min) [Min]	Number of Channels	Operating Temperature [Max]	Operating Temperature [Min]	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Technology	Supplier Device Package	Channel Type	Package / Case	Package / Case [y]	Package / Case [y]	Rise / Fall Time (Typ)	Rise / Fall Time (Typ) [Max]	Type	Utilized IC / Part	Supplied Contents	Secondary Attributes	Function
Texas Instruments ISOW1412DFMR	500 kbps	40 ns	1.89 V 5.5 V	1.71 V 2.25 V	610 ns	Surface Mount	100 kV/µs	4	125 °C	-40 °C	2	2	Magnetic Coupling	20-SOIC	Unidirectional	20-SOIC	0.295 in	7.5 mm	4 ns	4 ns	RS422 RS485
Texas Instruments ISOW1412BDFMR	500 kbps	40 ns	1.89 V 5.5 V	1.71 V 2.25 V	610 ns	Surface Mount	100 kV/µs	4	125 °C	-40 °C	2	2	Magnetic Coupling	20-SOIC	Unidirectional	20-SOIC	0.295 in	7.5 mm	4 ns	4 ns	RS422 RS485
Texas Instruments ISOW1412DFMEVM																					Interface	ISOW1412	Board(s)	On-Board Test Points	RS-422 RS-485 Transceiver
