SPB09C Series

Catalog

DC/DC CONVERTER

Part	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Features	Voltage - Output 1	Package / Case	Applications	Current - Output (Max) [Max]	Voltage - Isolation	Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Approval Agency	Efficiency	Mounting Type
MEAN WELL USA Inc. SPB09C-15	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	15 V	8-DIP Module 6 Leads	ITE (Commercial)	600 mA	1.5 kV	Isolated Module	0.44 in	0.94 "	0.38 in	CE EAC UKCA	88 %	Through Hole
MEAN WELL USA Inc. SPB09C-05	36 V	8 W	75 V	90 °C	-40 °C	1	Remote On/Off	5 V	8-DIP Module 6 Leads	ITE (Commercial)	1.6 A	1.5 kV	Isolated Module	0.44 in	0.94 "	0.38 in	CE EAC UKCA	85 %	Through Hole
MEAN WELL USA Inc. SPB09C-12	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	12 V	8-DIP Module 6 Leads	ITE (Commercial)	750 mA	1.5 kV	Isolated Module	0.44 in	0.94 "	0.38 in	CE EAC UKCA	88 %	Through Hole
MEAN WELL USA Inc. SPB09C-24	36 V	9 W	75 V	90 °C	-40 °C	1	Remote On/Off	24 V	8-DIP Module 6 Leads	ITE (Commercial)	375 mA	1.5 kV	Isolated Module	0.44 in	0.94 "	0.38 in	CE EAC UKCA	89 %	Through Hole
