BSC040 Series
Manufacturer: INFINEON
Beta
⌘K
OPTIMOS™ 5 N-CHANNEL POWER MOSFET 100 V ; SUPERSO8 5X6 SUPER COOL PACKAGE; 4 MOHM;
| Part | Supplier Device Package | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs [Max] | Input Capacitance (Ciss) (Max) @ Vds [Max] | Package / Case | Power Dissipation (Max) | Operating Temperature [Max] | Operating Temperature [Min] | Vgs (Max) | Mounting Type | Vgs(th) (Max) @ Id | Technology | FET Type | Drain to Source Voltage (Vdss) | Gate Charge (Qg) (Max) @ Vgs | Current - Continuous Drain (Id) @ 25°C |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | PG-WSON-8-2 | 6 V 10 V | 4 mOhm | 5300 pF | 8-PowerWDFN | 3 W 167 W | 175 °C | -55 °C | 20 V | Surface Mount | 3.8 V | MOSFET (Metal Oxide) | N-Channel | 100 V | 72 nC | 140 A |
 INFINEON | PG-TDSON-8-7 | 6 V 10 V | 4 mOhm | 5300 pF | 8-PowerTDFN | 2.5 W 139 W | 150 °C | -55 °C | 20 V | Surface Mount | 3.8 V | MOSFET (Metal Oxide) | N-Channel | 100 V | 72 nC | 100 A |
