TFS Series

Manufacturer: Ohmite

Catalog

THICK FILM RESISTORS - THROUGH HOLE 2WATT 270OHM 5% SURGE

Part	Tolerance	Temperature Coefficient	Features	Package / Case	Supplier Device Package	Composition	Power (Watts)	Resistance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension	Number of Terminations [custom]	Size / Dimension [z]	Power (Watts)	Size / Dimension	Size / Dimension	Power (Watts)
Ohmite TFSF270RJE	5 %	100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	2 W	270 Ohms	0.035 in 10.5 mm	0.413 in	0.413 " 26 mm	1.024 in	1.8 mm	0.071 in	200 °C	-55 C	0.9 mm	26 mm	10.5 mm	1.024 in	Rectangular	2
Ohmite TFSB51K0JE	5 %	100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	0.5 W	51 kOhms	0.7 mm	0.028 in	5.5 mm	0.217 in			200 °C	-55 C				11 mm		2	0.433 "	0.5 W
Ohmite TFSD100KJE	5 %	100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	1 W	100 kOhms	8 mm	0.315 in	21 mm	0.827 "	1.8 mm	0.071 in	200 °C	-55 C						2			0.9 mm 8 mm 21 mm	0.035 " 0.315 " 0.827 "
Ohmite TFSC4K70JE	5 %	100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	0.75 W	4.7 kOhms							200 °C	-55 C						2				0.028 in 0.217 in 0.512 in 0.7 mm 5.5 mm 13 mm	3/4W
Ohmite TFSD1K50JE	5 %	100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	1 W	1500 Ohms							200 °C	-55 C						2			0.9 mm 8 mm 21 mm	0.035 " 0.315 " 0.827 "
Ohmite TFSC1K50JE	5 %	100 ppm/°C 100 ppm/°C	Non-Inductive Pulse Withstanding	Axial	Axial	Thick Film	0.75 W	1500 Ohms	5.5 mm	0.217 in	13 mm	0.512 "	1.6 mm	0.063 in	200 °C	-55 C						2				0.028 in 0.217 in 0.512 in 0.7 mm 5.5 mm 13 mm	3/4W
