XPEBGR Series
Manufacturer: New Energy
Beta
⌘K
LED MOD XLAMP GREEN STARBOARD
| Part | Lens Type | Voltage - Forward (Vf) (Typ) | Luminous Flux @ Current/Temperature [Max] | Luminous Flux @ Current/Temperature | Luminous Flux @ Current/Temperature [Min] | Type | Current - Test | Wavelength | Color | Viewing Angle | Size / Dimension [diameter] | Configuration | Lumens/Watt @ Current - Test | Temperature - Test | Current - Max [Max] | Wavelength [Max] | Wavelength [Min] | Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 New Energy | Domed | 3.2 V | 139 lm | 135 lm | 130 lm | LED Module | 350 mA | 528 nm | Green | 135 ° | 19.89 mm | Starboard | 121 lm/W | 25 °C | 1 A | |||
 New Energy | Domed | 3.2 V | 130 lm | 126 lm | 122 lm | LED Module | 350 mA | 530 nm | Green | 135 ° | 19.89 mm | Starboard | 113 lm/W | 25 °C | 1 A | 535 nm | 525 nm | 2.3 mm |
