M80-792 Series

Catalog

CONN HEADER R/A 3POS 2MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Insulation Color	Number of Rows	Contact Shape	Insulation Material	Insulation Height	Insulation Height	Contact Length - Post	Contact Length - Post	Connector Type	Number of Positions Loaded	Features	Shrouding	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Fastening Type	Material Flammability Rating	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Style	Termination	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Contact Type	Mounting Type	Contact Finish - Post	Current Rating (Amps)	Number of Positions
Harwin Inc. M80-7920342	118.1 µin	3 µm	Black	1	Circular	Polyphenylene Sulfide (PPS) Glass Filled	0.156 in	3.96 mm	4.5 mm	0.177 in	Header	All	Strain Relief Clips	Shrouded - 4 Wall	0.079 "	2 mm	Gold	Latch Lock	UL94 V-0	120 VDC	-55 C	125 °C	Phosphor Bronze	Board to Board Cable	Solder	29.5 µin	0.75 µm	Male Pin	Right Angle Through Hole	Tin	2.2 A
Harwin Inc. M80-7920642	118.1 µin	3 µm	Black	1	Circular	Polyphenylene Sulfide (PPS) Glass Filled	0.156 in	3.96 mm	4.5 mm	0.177 in	Header	All	Strain Relief Clips	Shrouded - 4 Wall	0.079 "	2 mm	Gold	Latch Lock	UL94 V-0	120 VDC	-55 C	125 °C	Phosphor Bronze	Board to Board Cable	Solder	29.5 µin	0.75 µm	Male Pin	Right Angle Through Hole	Tin	2.2 A	6
Harwin Inc. M80-7920222	118.1 µin	3 µm	Black	1	Circular	Polyphenylene Sulfide (PPS) Glass Filled	0.156 in	3.96 mm	4.5 mm	0.177 in	Header	All	Strain Relief Clips	Shrouded - 4 Wall	0.079 "	2 mm	Gold	Latch Lock	UL94 V-0	120 VDC	-55 C	125 °C	Phosphor Bronze	Board to Board Cable	Solder	29.5 µin	0.75 µm	Male Pin	Right Angle Through Hole	Tin-Lead	2.2 A	2
