WBC Series

Manufacturer: Coilcraft

Catalog

AUDIO TRANSFORMERS / SIGNAL TRANSFORMERS WBC SMT MINI WDEBND 1:8 0.150-600 MHZ

Part	Turns Ratio - Primary:Secondary	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]
Coilcraft WBC8-1LC	1:8	3.04 mm	0.12 in	4.45 mm	0.175 in	0.165 in	4.19 mm	Surface Mount	85 °C	-40 C
Coilcraft WBC16-1TLC	1:4	3.04 mm	0.12 in	4.45 mm	0.175 in	0.165 in	4.19 mm	Surface Mount	85 °C	-40 C
