R12515 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA M RA SD.085 C100
| Part | Body Finish | Includes | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Center Contact Plating | Mating Cycles | Voltage Rating | Impedance | Connector Type | Contact Termination | Shield Termination | Cable Group | Fastening Type | Number of Ports | Frequency - Max [Max] | Housing Color | Mounting Type | Connector Style | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Gold | 1 Connector 1 End Cap | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 335 V | 50 Ohms | Plug Male Pin | Solder | Solder | RG-405 (.085" Semi Rigid) | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass |
 Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 335 V | 50 Ohms | Plug Male Pin | Solder | Solder | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | ||
 Radiall USA, Inc. | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 500 V | 50 Ohms | Plug Male Pin | Crimp | Crimp | Threaded | 1 | 18 GHz | Silver | Free Hanging (In-Line) Right Angle | SMA | Brass | |||
 Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 500 V | 50 Ohms | Plug Male Pin | Solder | Solder | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | ||
 Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 335 V | 50 Ohms | Plug Male Pin | Solder | Solder | RG-405 (.085" Semi Rigid) | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | |
 Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 V | 50 Ohms | Plug Male Pin | Solder | Solder | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | |||
Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 335 V | 50 Ohms | Plug Male Pin | Solder | Solder | RG-405 (.085" Semi Rigid) | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | |
 Radiall USA, Inc. | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 335 V | 50 Ohms | Plug Male Pin | Crimp | Crimp | RG-405 (.085" Semi Rigid) | Threaded | 1 | 18 GHz | Silver | Free Hanging (In-Line) Right Angle | SMA | Brass | |||
Radiall USA, Inc. | Gold | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 V | 50 Ohms | Plug Male Pin | Solder | Solder | Threaded | 1 | 12.4 GHz | Gold | Free Hanging (In-Line) Right Angle | SMA | Brass | |||
Radiall USA, Inc. | Stainless Steel | 105 ░C | -65 ░C | Polytetrafluoroethylene (PTFE) | Gold | 500 | 500 V | 50 Ohms | Plug Male Pin | Crimp | Crimp | Threaded | 1 | 18 GHz | Silver | Free Hanging (In-Line) Right Angle | SMA | Brass |
