LM3502 Series

Catalog

IC LED DRV RGLTR PWM 16WQFN

Part	Current - Output / Channel	Package / Case	Voltage - Supply (Min) [Min]	Voltage - Output	Operating Temperature [Max]	Operating Temperature [Min]	Dimming	Topology	Applications	Supplier Device Package	Voltage - Supply (Max)	Type	Mounting Type	Number of Outputs	Frequency	Supplied Contents	Voltage - Input [Min]	Voltage - Input [Max]	Utilized IC / Part	Outputs and Type	Outputs and Type
Texas Instruments LM3502SQX-44/NOPB	750 mA	16-WFQFN Exposed Pad	2.5 V	44 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	16-WQFN (4x4)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502ITL-44EV/NOPB	9 mA			44 V												Board(s)	2.5 V	5.5 V	LM3502	2	Non-Isolated
Texas Instruments LM3502ITL-44EV	9 mA			44 V												Board(s)	2.5 V	5.5 V	LM3502		2 Non-Isolated Outputs
Texas Instruments LM3502ITLX-35/NOPB	750 mA	10-WFBGA DSBGA	2.5 V	35 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	10-TµSMD (1.9x2.07)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502SQ-35	750 mA	16-WFQFN Exposed Pad	2.5 V	35 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	16-WQFN (4x4)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502SQX-35	750 mA	16-WFQFN Exposed Pad	2.5 V	35 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	16-WQFN (4x4)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502ITLX-25/NOPB	600 mA	10-WFBGA DSBGA	2.5 V	25 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	10-TµSMD (1.9x2.07)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502SQX-44	750 mA	16-WFQFN Exposed Pad	2.5 V	44 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	16-WQFN (4x4)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502SQX-35/NOPB	750 mA	16-WFQFN Exposed Pad	2.5 V	35 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	16-WQFN (4x4)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
Texas Instruments LM3502ITL-25/NOPB	600 mA	10-WFBGA DSBGA	2.5 V	25 V	85 °C	-40 °C	PWM	Step-Up (Boost)	Backlight	10-TµSMD (1.9x2.07)	5.5 V	DC DC Regulator	Surface Mount	2	1 MHz
